Part #: 1-6009

Part Number: 1-6009

Description: 9 Ply Neoprene FS x FS
Color : Brown
Plies: 9

Nominal OAG:

0.22

 +/-

0.02
Fabric:
Cotton/Polyester

Top Surface:

Friction Surface

Bottom Surface:

Friction Surface
Compound:
NBR
Work Tension:
90

Elongation:

Less than 2%

Weight:

0.118

Minimum Pulley Diameter:

4

Back Flex Min. Pulley Diameter:

6

Working Temperature:

0 to 250

Max. Stocked Width:

72
Attributes: Non-Marking

Top Cover Coefficient of Friction/Steel:

0.5

Bottom Cover Coefficient of Friction/Steel:

0.5
Features:

This belt features tighly woven fabric for general conveying. The belt is non-marking, very flexible, oil resistant and easy to clean. This belt can be made endless with cold vulcanizing cement as well as hot vulcanizing. 9 Ply Neoprene FS x FS is used to convey medium weight parts, particularly in oily applications. It is very popular in the folding carton and printing industries.

Gallery

Part Number: 1-6009

Description: 9 Ply Neoprene FS x FS
Color : Brown
Plies: 9
Nominal OAG: 0.22″
 +/- 0.02″
Fabric: Cotton/Polyester
Top Surface: Friction Surface
Bottom Surface: Friction Surface
Compound: NBR
Work Tension: 90 lbs./PIW
Elongation: Less than 2%
Weight: 0.118 lbs./PIW
Minimum Pulley Diameter: 4″
Back Flex Min. Pulley Diameter: 6″
Working Temperature (F): 0 to 250
Stock Width: 72″
Attributes: Non-Marking
Top Cover Coefficient of Friction: 0.5
Bottom Cover Coefficient of Friction: 0.5
MinPulleyChart: 0
Features:

This belt features tighly woven fabric for general conveying. The belt is non-marking, very flexible, oil resistant and easy to clean. This belt can be made endless with cold vulcanizing cement as well as hot vulcanizing. 9 Ply Neoprene FS x FS is used to convey medium weight parts, particularly in oily applications. It is very popular in the folding carton and printing industries.
