Part #: 6-1015

Part Number: 6-1015

Description: PT-10/15
Color : Green
Plies: 2
Nominal OAG: 0.06″
 +/- 0.01″
Fabric: Polyamide
Top Surface: Green Rough Texture
Bottom Surface: Yellow Rough Texture
Compound: NBR
Work Tension: 23 lbs./PIW
Elongation: Less than 1%
Weight: 0.026 lbs./PIW
Minimum Pulley Diameter: 1.6″
Back Flex Min. Pulley Diameter: 2.4″
Working Temperature (F): -4 to 212
Features:

6-1015 is an abrasion resistant power transmission belt. It is also used as a folder-gluer. 6-1015 is used in paper converting, folder-gluers, box making and yarn processing.

Gallery

Part Number: 6-1015

Description: PT-10/15
Color : Green
Plies: 2
Nominal OAG: 0.06″
 +/- 0.01″
Fabric: Polyamide
Top Surface: Green Rough Texture
Bottom Surface: Yellow Rough Texture
Compound: NBR
Work Tension: 23 lbs./PIW
Elongation: Less than 1%
Weight: 0.026 lbs./PIW
Minimum Pulley Diameter: 1.6″
Back Flex Min. Pulley Diameter: 2.4″
Working Temperature (F): -4 to 212
MinPulleyChart: 0
Features:

6-1015 is an abrasion resistant power transmission belt. It is also used as a folder-gluer. 6-1015 is used in paper converting, folder-gluers, box making and yarn processing.
