Part #: 6-1820

Part Number: 6-1820

Description: PT-18/20
Color : Green
Plies: 2

Nominal OAG:

0.08

 +/-

0.01
Fabric:
Polyamide

Top Surface:

Green Rough Texture

Bottom Surface:

Yellow Rough Texture
Compound:
NBR
Work Tension:
43

Elongation:

Less than 1%

Weight:

0.037

Minimum Pulley Diameter:

2.4

Back Flex Min. Pulley Diameter:

3.6

Working Temperature:

-4 to 212
Attributes: Anti-Static, Abrasion Resistant
Features:

6-1820 is an abrasion resistant power transmission belt. It is also used as a folder-gluer. 6-1820 is used in paper converting, folder-gluers, box making and yarn processing.

Gallery

Part Number: 6-1820

Description: PT-18/20
Color : Green
Plies: 2
Nominal OAG: 0.08″
 +/- 0.01″
Fabric: Polyamide
Top Surface: Green Rough Texture
Bottom Surface: Yellow Rough Texture
Compound: NBR
Work Tension: 43 lbs./PIW
Elongation: Less than 1%
Weight: 0.037 lbs./PIW
Minimum Pulley Diameter: 2.4″
Back Flex Min. Pulley Diameter: 3.6″
Working Temperature (F): -4 to 212
Attributes: Anti-Static, Abrasion Resistant
MinPulleyChart: 0
Features:

6-1820 is an abrasion resistant power transmission belt. It is also used as a folder-gluer. 6-1820 is used in paper converting, folder-gluers, box making and yarn processing.
